Vehicle parameters
|
Total length (mm)
|
1965
|
Overall width (mm)
|
730
|
Total height (mm)
|
1105, windshield height 1180
|
Wheelbase (mm)
|
1335
|
Seat height (mm)
|
808
|
Minimum ground clearance (mm)
|
85
|
Rear wheel ground clearance (mm)
|
40
|
Maximum speed (km/h)
|
100
|
Fuel supply (carburetor/electronic injection)
|
EFI
|
Front shock absorber type (upright/inverted/swing arm)
|
Upright
|
Front brake type (disc brake/drum brake)
|
Disc brakes
|
Rear brake type (disc brake/drum brake)
|
Disc brakes
|
Rear shelf/rear armrest
|
Rear shelf
|
Front wheel hub specifications
|
MT2.50×14
|
Rear wheel hub specifications
|
MT3.5×13
|
Front tire specifications
|
110/80-14
|
Rear tire specifications
|
130/70-13
|
Wheel material (aluminum wheel/iron wheel)
|
aluminum
|
Net weight of vehicle (kg)
|
131
|
Curb weight (kg)
|
139
|
Maximum load (kg)
|
150
|
Fuel tank capacity (L)
|
11L
|
Number of rear shock absorbers (single/double)
|
pair
|
Fuel consumption (L/100km)
|
|
Battery capacity
|
12V7AH
|
Suspension method (upper suspension/lower suspension/other)
|
Lower suspension
|
Instruments (mechanical/LCD/semi-LCD)
|
liquid crystal
|
Price
|
12,100 RMB
|
